XCMG XLC110MC – 110 Tonne Crawler Crane

General Description

The XLC110MC is a 100-tonne class lattice boom crawler crane designed for heavy lifting applications including civil construction, infrastructure, mining, and industrial projects.

Key Specifications

• Maximum lifting capacity: 110 t
  • Main boom length: 13–64 m
  • Fixed jib length: 7–19 m
  • Maximum boom + jib: 52 m + 19 m

Performance

• Hoisting speed: up to 140 m/min
  • Luffing speed: up to 75 m/min
  • Slewing speed: 2.1 rpm
  • Travel speed: 1.9 km/h
  • Gradeability: 30%

Engine

• Engine: Weichai WP7G270E301
  • Rated power: 199 kW @ 2100 rpm
  • Emission: China Stage III / EU Stage IIIA

Weights & Transport

• Operating weight: approx. 98 t
  • Ground pressure: 0.098 MPa
  • Max transport piece: 23.5 t
  • Transport dimensions: 13.6 × 3.4 × 3.1 m

Safety & Controls

• CAN-bus electro-hydraulic controls
  • 12.1-inch HD touchscreen
  • Load Moment Indicator (LMI)
  • Emergency stop & slew lock
  • Camera monitoring system
